Alech01 call system wireless nurse
Completely wireless professional nurse call system, this will give the possibility to install an entire ward in a few hours of work.
In fact, a few minutes' work will be required inside the rooms to perform only the fixing of the terminals near the beds,
all romm devices are battery powered with an expected duration ranging from 5 to 8 years depending on the number of calls made. the batteries used are commercial of the "AAA long life" type.
Calls can be received on fixed or portable devices mono or double-sided LED displays, digital monitors, software for recording call history and monitoring of intervention times
• Easy and immediate system installation
• Easy implementation even later
• Masonry works are not necessary
• Long operating distance
• The existing wi-fi network can be used
• The situation can be checked in real time
• Long battery life
TL-02W keyboard / terminal wireless call with cancellation
Wireless call module for call activation,, presence button, prepared with RJ45 socket for connection with the PR-L00 or PR-L01 patient terminal.
Patient terminal disconnection alarm.
Low Battery Alarm
Luminous LED and Beep for patient reassurance
Battery life: about 5 -8 years
Transmission type: RF 433.50 MHz
Protocol: Pocsag
Dimensions: 115 x 75 x 28 mm
accessories :
TL-02W keyboard / terminal wireless call with cancellation
Wireless call module for call activation, prepared with RJ45 socket for connection with the PR-L00 or PR-L01 patient terminal.
Patient terminal disconnection alarm.
Low Battery Alarm
Luminous LED and Beep for patient reassurance
Battery life: about 5 -8 years
Transmission type: RF 433.50 MHz
Protocol: Pocsag
Dimensions: 115 x 75 x 28 mm
accessories :
PR-L01
Patient terminal with call button and light control
Terminal in antimicrobic silicon, luminescent button e patient reassurance led and lights control
Disconnection system if subjected to traction greater than 3 Kg
complete with support, clips for sheets and 3m cable
dimensions: 85 x 45 x 20 mm
PR-L00
Patient terminal with call button
Terminal in antimicrobic silicon, luminescent button and patient reassurance led.
Disconnection system if subjected to traction greater than 3 Kg
complete with support, clips for sheets and 3m cable
dimensions: 85 x 45 x 20 mm
TL-01W wireless terminal with call and cancel
Wireless call module for call activation
suitable for outdoor mounting IP67 protection
Low Battery Alarm
Luminous LED and Beep for patient reassurance
Battery life: about 5 -8 years
Transmission type: RF 433.50 MHz
Protocol: Pocsag
Dimensions: 115 x 75 x 28 mm
TL-01WT wireless terminal with call and cancel
Wireless calling module with lanyard for call activation, suitable for installation in toilets etc.
Low Battery Alarm
Luminous LED and Beep for patient reassurance
Battery life: about 5 -8 years
Transmission type: RF 433.50 MHz
Protocol: Pocsag
Dimensions: 115 x 75 x 28 mm
CL-01BA wearable terminal with call and cancel functions
wearable terminal with fully waterproof rubber strap, allows you to make calls
even if you are not near your bed
Low Battery Alarm
Luminous LED and Beep for patient reassurance
Battery life: about 2 years
Transmission type: RF 433.50 MHz
Protocol: Pocsag
Dimensions: 45 x 35 x 12 mm
LT-01W
Wireless Led Door lamp , colors used: Red, green, white and blue.
RGB LED technology, multicolored division into 3 sectors, complete with sound alarm
according to VDE-834 standards
5V dc or 110 / 220Vac power supply with adapter
Size: 104 * 86 * 38
LD-02 Single-sided ( LD-02D double-sided version)
LD02 LED display allows you to view even multiple calls, the first call remains fixed on the first line any subsequent ones will be displayed in rotation on the second line
Clock function, acoustic alarm with night function (ringtone volume lowered by about 40%)
available TWO-SIDED version cod. LD-02D
Dimensions: 650 x 165 x 31 mm
Power supply voltage: 110-220Vac
LD-01 Single-sided ( LD-01D double-sided version)
LD01 led display allows the visualization of even multiple calls, the first call remains fixed on the first line any subsequent ones will be displayed in rotation on the second line
Clock function, acoustic alarm with night function (ringtone volume lowered by about 40%)
available TWO-SIDED version cod. LD-01D
Dimensions: 350 x 165 x 31 mm
Power supply voltage: 110-220Vac
AD5003
21 ”digital wall monitor with indication of calls in progress and those on hold complete with bracket.
• Calls will change color based on waiting times set green-yellow-red. Priority call management
• The first call displayed in large at the top of the monitor
and other calls will be displayed at the bottom in sequence.
• Indication of current time and total number of calls waiting.
• Continuous or silent ringtone selection
Dimensions: 520 x 340 x 50 mm
Power supply: 110 / 220Vac
SOFT-MN2
PC 21 "with monitoring software, allows you to manage and monitor the calls received.
It is possible to view reports relating to call response times divided by various sectors such as:
• call area • call key • call operator • day and time etc.
The system also allows the management of scheduled maintenance, battery alarms, priority calls
complete with RF reception system
Dimensions: 520 x 340 x 50 mm
Power supply: 110 / 220Vac
